Integriti Access Controller (IAC) PCB Only

996035PCB&K

The Integriti Access Controller (IAC) is a state-of-the-art IP connected intelligent Controller designed for Access Control applications. The IAC can directly manage up to 8 doors locally or up to 250 doors via RS-485 Sub-LAN expansion. All decision making is intelligently processed by the Controller with no reliance on the system server (should the connection to the server be offline). The result is a solution that is incredibly quick, robust and highly intelligent.


The main Controller is equipped with connections for 2 Doors and 4 Wiegand Card Readers, a Watchdog Output, Ethernet and USB ports and a dedicatedRS-485 reader port. Additional connections for Doors and Wiegand Readers can be added via the IAC’s UniBus port with up to 3 UniBus 2 Door/2 Reader expansion devices (Part. 996535PCB&K), this allows for flexible configurations of 2, 4, 6 or 8 doors, and up to 10 Wiegand readers.


The RS-485 Reader port accommodates up to 16 Inner Range SIFER or compatible third party OSDP multi-drop readers, providing ‘in & out’ directional access control for each door. The IAC can also be sed for integration of wireless door locking systems from Assa Abloy Aperio, SimonsVoss or Salto Sallis. See the Wireless Locking system Integration Guides on the Inner Range website for more details.


Larger systems may consist of many IAC’s networked together to form an enterprise-wide IP connected intelligent access control solution. Each IAC can support up to 3,000 Zone Inputs, 3,000 Outputs, 250 Areas and over 1,000 Card Readers and 250 Doors. User capacity of up to 100,000 users is available, and capacity for 1,000,000 users is also available with the User expansion kit. (Part. 996002L5)

Integriti Access Controller (IAC) PCB Only
Controller Features
  • 2 Door Interfaces (Lock Relays) expandable to 8 via UniBus

  • Reader Port – Encrypted RS-485, Up to 16 SIFER Readers

  • Reader Port – RS-485/OSDP, Up to 16 compatible OSDP Readers

  • Wiegand Reader ports – 4, expandable to 10 via UniBus

  • Aperio, SimonsVoss, Salto Sallis integration - up to 8 Doors via RS-485 Reader port

  • 2 DOTL Relay Outputs, expandable to 8 via Unibus

  • RJ45 - 10/100 Ethernet Port

  • SkyTunnel/Multipath-IP Alarm reporting (via RS-232 STU device)

  • Peer-to-Peer Dialler Alarm Reporting (via an ISC Controller)

  • Advanced Peer-to-Peer Mode

  • RS-485 Sub-LAN

  • USB Master & Slave Ports

  • UniBus In-Cabinet Expansion Interface

  • Dedicated Watch Dog Output

  • Dedicated Tamper Input

  • 32 Bit ARM CPU, 64 MB RAM, 4 GB Micro SD Memory

  • Firmware Upgrade via USB or Software

  • Choice of 3Amp or 8Amp Power Supply and enclosure options

  • Built-in module locater buzzer
