Inner Range
Mobile Access
Utilizing smartphone Bluetooth technology for building access control enhances the flexibility of traditional security measures offering convenience, enhanced functionality and more accurate identification of who is on site and when. Users gain entry to buildings by approaching the Bluetooth enabled readers at the access points and unlock the door with their smart phones eliminating the need for physical keys or access cards.
Inner Range put SECURITY FIRST
Inner Range puts SECURITY FIRST when it comes to controlling access to a premises. The systems hardware infrastructure is installed securely on site behind the network security policies of the organisation ensuring that critical data is safe and secure from would be hackers or cyber criminals. Unlike other cloud-based security systems, the Inner Range solution keeps all critical information and user data secure in the controller and onsite software. However, we also provide an exceptional remotely connected end user experience through our IR Connect cloud connected service. Total cost of ownership is dramatically reduced by not having costly cloud based subscription services that also expose your organisation to cybercrime.
Cloud-Based
Control
Centralized access control management seamlessly connected through the cloud for ease of use from any remotely connected location.
Local Secure
Management
Access control managed locally on-site behind the network security policies of the organisation.
Authorized
Entry Only
Ensuring that who is on site is accurately identified and is permitted on site.
Scalable
Access Control
Scalability from entry to enterprise global projects with varying numbers of users and locations.
Real-Time
Alerts
Real-time monitoring and reporting of access events.
System
Integration
Easily integrated to other cloud connected services and sub systems (e.g., video surveillance, visitor management)
Encrypted
Security
Enhanced security through encrypted communication and authentication protocols.
Custom
User Roles
Customizable access levels and permissions for different user roles.
The Mobile Access Readers and Keypads are a combined Bluetooth enabled, IP67 rated, SIFER Smart Card Keypad and Reader that supports both Bluetooth mobile credentials and SIFER physical access cards and fobs as well as PIN (Keypad version) for access control. The Keypad / Reader allows dual credential Mobile Credential / Card & PIN high security access control (PIN only or Mobile Credential / Card only is also supported).
They are multi-drop RS-485 based devices that employ 128-bit AES encryption from the card through to the door module, providing a far superior level of security than that of traditional Wiegand based card readers.
They utilise the Mifare DESFire© EV1/EV2/EV3 card format and utilise a superset of the OSDP protocol, which allows the Readers and Keypads to be deployed on any system capable of using OSDP. They are connected to the RS-485 reader port for full Reader-In and Reader-Out operation of various Inner Range products as below.
-
Integriti Access Controller (IAC) - Up to 16 Readers on-board.
-
Intelligent LAN Access Module (ILAM) - Up to 16 Readers.
-
Standard LAN Access Module (SLAM) - Up to 4 Readers.
-
Inception Controller - Up to 8 Readers on-board.
The Mobile Access Keypads and Readers are IP67 rated and available with site-specific encryption keys.
Mobile Access Reader & Keypad
The Inner Range Mobile access credentials are created, managed and delivered by the security controller onsite that is installed safely behind the network security infrastructure and cyber security policies of the orgsanisation.
Securely delivered through the IR Connect cloud service to the end users smart device, the Mobile Access credential is then accepted and saved into the IR Mobile Access Mobile App that is installed on the smart device.
When access to a door is required the smart device is unlocked, the IR Mobile Access App is opened and then the appropriate door is selected and unlocked. This process provides user authentication through the devices biometric credential ensuring the identity of the user.
Mobile Access credentials are available for:
Inception – 994635ICP
Integriti - 994635
Infiniti - 994635INF
Mobile Access Credentials
